UR30
Heavy payload, compact cobot
The UR30 can lift heavy payloads while maintaining a compact footprint in a collaborative setting. With a 30 kg lifting capacity and a 1300 mm reach this robot can tend larger machines, palletize heavy products, and effectively support high torque screw driving.
Reach
1300 mm / 51.2 in
Payload
35 kg / 77.16 lbs
Footprint
Ø 245 mm
Weight
63.5 kg / 139.9 lbs
Strength redefined
The UR30 is no longer bound by its namesake but will now offer an increased payload capacity of 5 kilograms, bringing the total payload to 35 kilograms for certain movements. By redefining the way the UR30 can be utilized we’re empowering you with solutions that can improve production and strengthen your business.
This new payload will be introduced in PolyScope 5.19.
Performance in a compact size
Building off the same architecture as the UR20, the UR30 offers extraordinary lift in a compact footprint with superior motion control ensuring the perfect placement of large payloads. With the ability to handle higher torque, the UR30 opens the door for precise screw driving and the 30 kg payload brings productivity to everything from machine tending with multiple grippers to palletizing heavy parts.
Motion Control
The UR30 received software enhancements to reduce the stress on the mechanics of the arm and the new joint architecture to a minimum. Take advantage of the cobots full speed range and accelerations despite lifting the maximum payload at maximum reach.
Perfect precision
The UR30s high torque joints and force torque sensor allow for straight, consistent screw driving even in areas difficult for humans to reach and steady mode prevents protective stop while maintaining safety.
